Circuit Board Tester for Electronic Repair

The easiest way to find fault in the electronic cards is to use FAdos7f1

1. Dual – Channel Fault Detection by V / T tester (Analog Signature Analyzer – Trouble Shooting)
Fault detection by direct comparison of the current-voltage characteristics (signatures) of a working and a faulty circuit board without applying power to the unit under test
2. Fault Detection by Comparison with Stored Signatures (Memory)
Signatures of a functioning board can be saved and used at a later time as a reference for troubleshooting a faulty board. The point to touch can be indicated by a cross hair mark at an image of the board
3. Equivalent Circuit Diagram
Display of an equivalent circuit that corresponds to the characteristic on the touched point
4. Display Values of Resistor, Capacitor and Diode Threshold
Display the calculated values of resistance, capacitors and diode threshold voltages corresponding to the conditions at the contacted node
5. Dual – Channel Digital PC Oscilloscope
As occasion may require, device can be used as oscilloscope
6. 0.2… 25KHz Square Wave Signal Output
Channel 2 is used as a square wave generator. Channel 1 can be used as an oscilloscope
7. Analogue Voltage Output (2,5 mV Sensitivity)
Channel 2 is used as Analog DC output -10 V +10 V. Channel 1 can be used as an oscilloscope
